CAMERA
Beeldsensor 1/2.9” Progressive Scan CMOS Starlight Sensor
Lens Focal Length: 4.3 mm
Aperture: F1.6
Field of View: 100° (Diagonal), 83°(Horizontal), 43°(Vertical)
Night Vision 1 × 850 nm IR LED (30 ft / 9 m)
2 × 940 nm IR LED (30 ft / 9 m)
Lighting /
Hub Compatibility /
Interface & Button 1× RESET Button
1× Privacy Button
1× MicroSD Card Slot (Up to 512 GB)
View Range 360° Horizontal, 149° Vertical
Pan/Tilt Range Pan Mechanical Range: (360° Pan Coverage)
Tilt Mechanical Range: (149° Tilt Coverage)
HUB
Device Compatibility /
Connection Capacity /
Interface & Button /
VIDEO & AUDIO
Maximum Resolution 2K QHD 4MP (2688 × 1520 px)
Frame Rate 15/20/25/30 fps (Default 15fps)
Digital Zoom None
Video Compression H.264
Live View Yes
Image Enhancement 3D DNR WDR
HDR
Audio Input & Output Built-in Microphone and Speaker
Audio Communication Two-Way Audio with Noise Cancellation
Siren Volume 98dB (Level measured at 4-inch/10-cm distance)
STORAGE
Local Storage MicroSD Card Slot on Camera (Up to 512 GB)
General Information about using MicroSD Cards >
Cloud Storage Tapo Care Cloud Storage Services (Subscription required)
DETECTION and NOTIFICATIONS
Sensor /
AI Detection Motion Detection
Person Detection
Line-Crossing Detection
Tamper Detection
BabyCry Detection
Vehicle Detection
Pet Detection
Meow Detection
Bark Detection
Glass-Breaking Detection
Activity Zones Yes
*Only works with Motion Detection.
Output Notification System Notification
System Notification with Snapshot (Tapo Care Services)
Netwerk
Network Connectivity Connect via Wi-Fi
Wireless Connectivity IEEE 802.11b/g/n/ax, 2.4 GHz Wi-Fi
Ethernet Port /
RTSP Yes
ONVIF Yes
Beveiliging
Security On-Device Machine Learning
128-bit AES Encryption with SSL/TLS
WPA/WPA2-PSK/WPA3
POWER
Power Source 12V DC Power Adapter
Power consumption in networked standby: 1.34 W
Power consumption in networked standby when all wireless network ports are activated: 1.34 W
The default period of time after which the power management function switches the equipment automatically into a condition providing networked standby or low power mode: 20 minutes
Input Voltage 100-240 V, 50/60 Hz
Output Voltage 12 V, 1.0 A (DC Power)
Algemeen
Smart Integration Google Assistant, Amazon Alexa, Apple HomeKit
Weather Resistance /
Mounting Options Tabletop
Ceiling-Mounted
Operating Temperature 0℃~40℃
Storage Temperature -20℃~70℃
Operating Humidity 10%~90% RH, Non-condensing
Storage Humidity 5%~90% RH, Non-condensing
Charging Temperature /
Dimensions ( W x D x H ) 3.15 × 3.15 × 4.41 in (80 × 80 × 112 mm)
